Portable Battery Hydraulic Crimper TRC-P20CS — 80TON Cordless Car Service | TRCrimp
The TRC-P20CS battery hydraulic crimper delivers 80TON / 800kN without a power cord — the compact cordless option for car service mechanics. Handles 10–54mm hose up to 3/4″ 4SP with 12 standard P18 dies. This battery hydraulic crimper works wherever the job is, whether in the workshop or out on a service call.
Description
| Max Crimping Dia (mm/inch) | 10-61 / 0.39-2.40 |
| Crimping Force (kN/ton) | 1370 / 137 |
| Hose Size ID (inches) | 1 1/2″(2SN) / 1 1/4″(4SP) |
| Cycle Time 10mm / Hourly Output | 7.2s / 200 pcs |
| Motor Power (12V/24V) | 1.6kW / 2.25kW |
| Max. Opening (mm) | +25 (109 w/o dies) |
| Oil Tank Volume (L) | 4 |
| Machine (mm/inch) | 600x480x480 / 23.6×18.9×18.9 |
| Package (mm/inch) | 830x630x600 / 32.7×24.8×23.6 |
| Net Weight (N.W.) | 110 KG |
| Gross Weight (G.W.) | 138 KG |
| Die Set No. | Range (mm) | ID (mm) | L (mm) |
| P20/06* | 6.0-8.0 | 6 | 55 |
| P20/08* | 8.0-10.0 | 8 | 55 |
| P20/10* | 10.0-12.0 | 10 | 55 |
| P20/12* | 12.0-14.0 | 12 | 55 |
| P20/14* | 14.0-16.0 | 14 | 55 |
| P20/16 | 16.0-19.0 | 16 | 55 |
| P20/19 | 19.0-23.0 | 19 | 55 |
| P20/23 | 23.0-27.0 | 23 | 55 |
| P20/27 | 27.0-31.0 | 27 | 70 |
| P20/31 | 31.0-36.0 | 31 | 70 |
| P20/36 | 36.0-41.0 | 36 | 75 |
| P20/41 | 41.0-47.0 | 41 | 75 |
| P20/47 | 47.0-54.0 | 47 | 85 |
| P20/54* | 54.0-61.0 | 54 | 85 |
What Is the TRC-P20CS Battery Hydraulic Crimper?
The TRC-P20CS battery hydraulic crimper is the compact cordless solution for mechanics who need 80TON of crimping force at the job site, not in the workshop. Handles hose from 10mm to 54mm (up to 3/4″ 4SP / 1″ 2SP) with 12 standard P18 dies covering the most common car service hose sizes. The 12V/24V battery system powers this battery hydraulic crimper anywhere — shop floor, service bay, or roadside call.
80TON Cordless Battery Hydraulic Crimper
At 80TON / 800kN, the P20CS battery hydraulic crimper handles the hose sizes most common in passenger vehicle hydraulic systems. The 2.0kW DC motor delivers consistent crimping force from the battery, while the semi-auto control keeps operation straightforward — position the hose, step on the pedal, done. Weights 68.8kg with a 600×355×585mm footprint on this battery hydraulic crimper.
Mobile Battery Hydraulic Crimper for Car Service
The P20CS battery hydraulic crimper is compact enough to move between service bays and take on roadside calls. No power cords, no generators, no hunting for an outlet — just battery power and the crimper. The 2.6L integrated oil tank maintains stable pressure across continuous sessions, and die wall racks keep the 12 P18 dies organized in the mobile workshop.
