TRC-120L Hydraulic Hose Crimper — 245TON CNC Heavy Duty Production | TRCrimp
The TRC-120L is a heavy-duty <strong>hydraulic hose crimper</strong> engineered for industrial production environments. Delivering 245TON / 2450kN of force through CNC precision control, it handles 6–118mm hose diameters — from 2″ R13 4-wire to 3″ industrial hose — at a 1.8-second cycle for high-volume production workflows.
Description
| Max Crimping Dia (mm / inch) | 118 / 4.65 |
| Max Crimping Force (kN / Tonnage) | 2450 / 245 |
| Cycle Time 10mm (s) | 1 |
| Hose Size ID (inches) | 2″ (R13) |
| Max Opening With/Without Dies | +52mm / 170mm |
| Master Die D / L (mm) | 118 / 97 |
| Motor Power (kW / HP) | 4 / 5.44 |
| Oil Tank Volume (L) | 70 |
| Voltage (V) Tri-Phase | 200 – 440 |
| Machine (mm / inch) | 900x800x1500 / 35.4×31.5×59.1 |
| Package (mm / inch) | 1025x1025x1740 / 40.4×40.4×68.5 |
| Net Weight (N.W.) | 790 KG |
| Gross Weight (G.W.) | 840 KG |
| Die Set No | Range (mm) | L (mm) |
|---|---|---|
| P20 Series (Adapter Required) | ||
| P20/14 | 14.0 – 16.0 | 55 |
| P20/31 | 31.0 – 36.0 | 70 |
| YB120L Series | ||
| YB120L/52 | 52.0 – 57.0 | 85 |
| YB120L/69 | 69.0 – 74.0 | 115 |
| YB120L/100* | 100.0 – 110.0 | 115 |
What Is the TRC-120L Hydraulic Hose Crimper?
The TRC-120L is a heavy-duty hydraulic hose crimper designed for industrial production environments. As part of TRCrimp’s heavy-duty CNC series, this 245TON machine handles hose assemblies from 2″ R13 4-wire spiral to 3″ industrial hose — covering the most demanding sizes in mining, construction, and heavy equipment applications.
CNC Precision Control for Industrial Hydraulic Hose Crimping
The 120L’s CNC control system delivers digital precision across every hydraulic hose crimping cycle. Features include correction offset, step crimping for sensitive fittings, quality report generation, and production data save — providing full traceability for ISO-certified industrial workshops and quality management systems.
Speed and Output of a Heavy Duty Hydraulic Hose Crimper
A 1.8-second crimp cycle makes the 120L one of the fastest heavy-duty hydraulic hose crimper machines in its class. Combined with a 70L integrated oil tank and 4kW / 5.44HP motor, it maintains consistent 245TON force delivery under continuous production workloads. The electric backstop and auto continuous foot pedal enable efficient hands-free operation.
Die Compatibility Across the Hydraulic Hose Crimper Range
The 120L uses the P20 die series for standard 10–67mm hose plus YB120L extended dies (25–119mm), covering a 6–118mm diameter range in one machine. The QuickChange-tool system enables rapid die changes during production runs of hydraulic hose crimping.
Engineered for Harsh Industrial Environments
Rated for mining, construction, and heavy industrial applications, the 120L operates on tri-phase 200/220/380/400/440V power globally. Its 1100×830×1600mm footprint and 790kg weight provide the stability for vibration-free precision hydraulic hose crimping under the most demanding production schedules.
Applications for the TRC-120L Hydraulic Hose Crimper
This heavy-duty hydraulic hose crimper is purpose-built for:
- Mining equipment hydraulic hose repair and production
- Construction heavy machinery hose assembly
- Industrial workshop high-volume hose production
- Heavy-duty production lines processing 2″ to 3″ hydraulic hose
